T-MOTOR’s ALPHA ESCs utilize cutting-edge FOC (Field Oriented Control) technology to ensure efficient, accurate and stable motor control, providing low noise, faster response times and linear throttle response. Intelligent algorithms allow the controller to monitor voltage, current, temperature and other parameters in real time, adjusting as necessary to ensure optimal operation and longer lifespans.
The lightweight rugged motor controllers are IP55-rated and resistant to corrosion from chemicals such as pesticides. An innovative cooling design allows the units to function in high-temperature environments.
Specifications:
| 40A 6S | 60A 6S | 60A 12S | 60A 24S | 80A 12S | 120A 12S | |
| Dimensions (L x W x H) |
64.5×29.4×14.7 mm | 71.3×32.5×15.9 mm | 78.7×32.5×16.2 mm | 110x55x25 mm | 88.5×36.6×19 mm | 110x55x25 mm |
| Weight (inc. cables) |
54.5g | 62.8g | 73g | 360g | 110g | 359.5g |
| Voltage | 18-25.2V | 18-25.2V | 18-50.4V | 40-100V | 18-52.2V | 18-50.4V |
| Continuous Current | 40A | 40A | 60A | 40A | 80A | 100A |
| Peak Current | 60A | 60A | 80A | 60A | 100A | 120A |
| Throttle Refresh | 500 Hz | |||||
| Throttle Response | 120 ms | 50 ms | 300 ms | 50 ms | 300 ms | 500 ms at startup, then 150 ms |
