The Maxtena M10HCT-A-TNC antenna, paired with the U-Blox X20 GNSS receiver, delivers a high-precision solution that fully supports E6 frequencies, unlocking exceptional GNSS accuracy for demanding applications.
This powerful combination enhances signal reception and processing, providing unmatched performance for critical navigation and positioning systems.
M10HCT-A-TNC: Advanced L1-L2-L5 Active Antenna for Precision Navigation
The Maxtena M10HCT-A-TNC is a versatile L1-L2-L5 active GNSS antenna solution, designed to support full GPS, Galileo, Glonass, and BeiDou bands, including L-Band correction services. With its low-profile, right-hand circular polarized (RHCP) design, the M10HCT-A-TNC is optimized for high-precision applications such as autonomous vehicle navigation, unmanned ground vehicles (UGVs), and maritime positioning.
Powered by Maxtena’s proprietary Helicore® technology, this antenna offers exceptional pattern control, polarization purity, and high efficiency in a compact form factor.
By integrating with the U-Blox X20 GNSS receiver, the antenna’s performance is significantly enhanced, enabling precise E6 frequency processing, which ensures high reliability in critical applications.
Key Features:
- Full GPS, Galileo, Glonass, BeiDou bands support, including L-Band correction services
- Low axial ratio for improved RHCP signal capture and minimized LHCP signal reflections
- Ground-plane independent, offering flexible installation options without the need for a dedicated ground plane
- Low noise figure for superior signal-to-noise ratio (SNR) and robust GNSS tracking across all environments
- Low power consumption for energy-efficient operation
- Rugged IP67 rating ensures durability in harsh conditions
- RoHS compliant and automotive-grade electronics for reliable long-term performance
Applications:
- UAVs/Drones
- Unmanned Ground Vehicles (UGVs)
- High-Precision Navigation
- Military & Security Systems
- Agriculture & FarmTec
- Marine Systems
M10HCT-A-SMA: Flexible Magnet Mount for Seamless Integration
The M10HCT-A-SMA version of the Maxtena M10HCT-A offers the same high-performance GNSS reception as the screw-mount version, but with a convenient magnet mount, enabling flexible integration for mobile applications. This version retains support for full GPS, Galileo, Glonass, BeiDou, and L-Band correction services. Like the TNC version, the M10HCT-A-SMA antenna uses Maxtena’s Helicore® technology to provide high-efficiency signal reception and reliable performance across a wide range of environments.
Key Features:
- Full-band support for GPS, Galileo, Glonass, BeiDou, and L-Band correction services
- Low axial ratio ensures optimal RHCP signal reception, reducing signal interference
- Ground-plane independent design, making it adaptable for diverse mounting configurations
- Rugged IP67 rating for durability in extreme weather conditions
- RoHS compliant and built with automotive-grade electronics
Applications:
- UAVs/Drones
- Unmanned Systems
- High-Precision Navigation
- Military & Security Systems
- Agriculture & FarmTech
- Marine Systems
