T-DRONES has released the VA23, an ultra-long endurance electric multipurpose VTOL UAV.
The VA23 is a high-performance VTOL fixed-wing UAV with a payload capacity of 2.5kg and a flight time of up to 4 hours without a payload.
The VA23 is made of carbon fiber, a lightweight material that allows the drone to remain relatively lightweight while maintaining structural strength, and is important for the flight performance and endurance of the UAV.
VA23 is equipped with a power management module and locking propeller function for longer flight time, and also has a backpack-type packing box, which makes transportation lighter and smaller.
In addition, the VA23 is equipped with a quick-detachable device, making the assembly and disassembly of the drone more convenient. Such a design makes it easier to package drones during transportation, saving time and labor costs. The design of the quick-detachable device also improves the portability of the drone, making it more suitable for rapid deployment and shipping between different locations.
| Model | VA23 |
| Frame Length | 1250mm |
| Weight | 2kg |
| Frame Material | Carbon Fiber |
| Flight Time | Max 240 mins (without payload) and max 180 mins (1.5kg payload) |
| Payload | 2.5kg |
| Max Range | 240km |
| Wind Resistance | Level 5 |
| Working Temperature | -10 to 40℃ |
| Control Range | 10km – 30km |
| Cruising Speed | 18-20 m/s |
| Max Flying Speed | 35 m/s |
| Max Take-Off Altitude | 4500m |
| Recommended Battery | 12s 22000mah/12s 27000mah/12s 30000mah |
